PL-4.0-2B 2 Post Lift Floor Cover Plate Two Post Vehicle Lift

The PL-4.0-2B 2 Post Lift is floor plate has been redesigned to now include standard features such as single-piece column construction, internal hose routing, added overhead shut-off bar with the kill switch, reduced overall width, drop-in adjustable swivel pads with height adapters, rubber door guards, making these models one of the best two post lift values in the industry!

SKU: PL-4.0-2B 2 Post Lift Categories: ,

Description

The PL-4.0-2B 2 Post Lift floor plate has been redesigned to now include standard features such as single-piece column construction, internal hose routing, added overhead shut-off bar with the kill switch, reduced overall width, drop-in adjustable swivel pads with height adapters, rubber door guards, making these models one of the best two post lift values in the industry!
Features:
. Elegant appearance with hidden cable and pipeline.
. Adopt 4 safety hooks, balanced fixed, protect the lift front-rear balance and
reduce the abrasion and deformation of the machine to the maximum extent, improve the safety performance of the lift
. External locked safety device, easy to inspect and maintain
. The equalization of two steel cables forces both sliding blocks to move synchronously, effectively preventing the vehicle from tilting
. The minimum height of the lifting pad is 125 mm, easily lift, and suitable for low-profile cars and SUVs.
. Equip aluminum motor and car door-opening protection as standard configuration.
. Reliable oil cylinder, adopts chrome-plating honed cylinder and piston rod, with Italian seals on hydraulic rams, ensure the long service life
. Passed 115% dynamic test and 150% static test

Additional information

Product

Floor Cover Plate Two Post Vehicle Lift

Product Code

PL-4.0-2B 2 Post Lift

Capacity

4.0 T

Lifting height

1800 mm 70.9"

Min height

110 mm 4.3"

Max car width

2576mm 101.4″

Power supply

220V 1PH 50/60Hz 2.2KW 220/380V 3PH 50/60Hz 2.2KW

Release

Dual manual Lock Release
